What Makes ClearML the Best Zero Integration MLOps Solution?

ClearML is an open-source, zero-integration machine learning/deep learning experiment manager and ML-Ops solution. It integrates using just two lines of code. Additionally, like GitHub, ClearnML has version control, but without worrying about conflicts, commit issues. The scalable design of ClearML aims to help developers and researchers manage complex projects with minimal integration effort. It comes with a plethora of helpful functionalities such as:

Saving ML models and datasets that can be shared on cloud storage systems.
Displaying a summary of python packages used in experiments with their specific version.
Web UI for remotely stopping, monitoring, and running experiments.

The Python package integrates ClearML into your existing code using two lines of code. The ClearML server stores experiments, models, and workflow data, and the Web UI experiment manager. It is available as a hosted service and open source for you to deploy your own server. ML-Ops orchestration is done by the ClearML agent that can be on a remote system.

Installing and setting up ClearML client and agent

To run a client you need to register an account on a ClearML-server here. You’ll be prompted to create credentials in the getting started screen, generate them, and copy them to your clipboard for later.

Install clearml client

pip install clearml

To configure the client run

clearml-init

Paste the credentials you generated earlier and confirm the default configuration for the Host, Web App, API, and Filestore.

Integrating with two lines of code

 from clearml import Task
 task = Task.init(project_name='hello', task_name='hello world')
 print("Analytics India")

When this is run, the output is not only printed on your machine but also logged in the server.

An agent is needed to run experiments, pipelines, and automation. Remember, we ran the hello world task locally on our system. The agent should be installed and configured on the machine you want it to run.

pip install clearml-agent

Configure the agent just like the client.

clearml-agent init

Start the agent in foreground mode. This means the agent will print the output to the screen. In actual service mode, the output will be stored automatically into a temporary file.

clearml-agent daemon --queue default --foreground

Creating a simple ML pipeline using ClearML

We’re going to create a very basic pipeline with three stages- The first stage will upload the dataset artifact, the second stage will process the data, and the final stage will create and train the model.

Create experiment tasks corresponding to the three stages

Downloading the data and storing it as an artifact named dataset(stage_one.py)

 from clearml import Task, StorageManager
 task = Task.init(project_name="pipeline", task_name="pipeline step 1 dataset artifact")

 # only create the task, it will be executed remotely later
 task.execute_remotely()

 # simulate local dataset, download one, so we have something local
 local_iris_pkl = StorageManager.get_local_copy(
     remote_url='https://github.com/Aditya1001001/machine-learning-basics/blob/master/iris_dataset.pkl')

 # add and upload local file containing the dataset
 task.upload_artifact('dataset', artifact_object=local_iris_pkl)

 print('uploading artifacts in the background')
 print('Done')

Getting the data from the previous task, processing it, and uploading the processed data(stage_two.py)

 import pickle
 from clearml import Task, StorageManager
 from sklearn.model_selection import train_test_split


 Task.init(project_name="pipeline", task_name="pipeline step 2 process dataset")
 # Use either dataset_task_id to point to a tasks artifact or
 # use a direct url with dataset_url
 args = {
     'dataset_task_id': '',
     'dataset_url': '',
     'random_state': 42,
     'test_size': 0.2,
 }
 # store arguments, these will be changed in the cloned task when the pipeline is run
 task.connect(args)
 print('Arguments: {}'.format(args))

 # only create the task, we will actually execute it later
 task.execute_remotely()

 # get dataset from task's artifact
 if args['dataset_task_id']:
     dataset_upload_task = Task.get_task(task_id=args['dataset_task_id'])
     # download the artifact
     iris_pickle = dataset_upload_task.artifacts['dataset'].get_local_copy()
 # get the dataset from a direct url
 elif args['dataset_url']:
    # simulate local dataset
     iris_pickle = StorageManager.get_local_copy(remote_url=args['dataset_url'])
 else:
     raise ValueError("Missing dataset link")

 # open the local copy of the dataset
 iris = pickle.load(open(iris_pickle, 'rb'))
 # "process" data
 X = iris.data
 y = iris.target
 X_train, X_test, y_train, y_test = train_test_split(
     X, y, test_size=args['test_size'], random_state=args['random_state'])

 # upload the processed data
 print('Uploading process dataset')
 task.upload_artifact('X_train', X_train)
 task.upload_artifact('X_test', X_test)
 task.upload_artifact('y_train', y_train)
 task.upload_artifact('y_test', y_test)

 print('Notice, artifacts are uploaded in the background')
 print('Done')

Creating, training, and storing the model(stage_thrre.py)

 import joblib
 import numpy as np
 from sklearn.linear_model import LogisticRegression
 from clearml import Task

 task = Task.init(project_name="pipeline", task_name="pipeline step 3 train model")

 # This will be changed in the cloned task when the pipeline is run
 args = {
     'dataset_task_id': '',
 }

 task.connect(args)
 task.execute_remotely()

 print('Retrieving Iris dataset')
 dataset_task = Task.get_task(task_id=args['dataset_task_id'])
 X_train = dataset_task.artifacts['X_train'].get()
 X_test = dataset_task.artifacts['X_test'].get()
 y_train = dataset_task.artifacts['y_train'].get()
 y_test = dataset_task.artifacts['y_test'].get()
 print('Iris dataset loaded')

 model = LogisticRegression(solver='liblinear', multi_class='auto')
 model.fit(X_train, y_train)

 joblib.dump(model, 'model.pkl', compress=True)
 loaded_model = joblib.load('model.pkl')
 result = loaded_model.score(X_test, y_test)

 print('model trained & stored')
 print('Done')

Run the three stages in order to create the base task in the server.

Base tasks on CLearML server — Base tasks created in the server.

Create a pipeline, add the three stages and run it(controller.py).

 from clearml import Task
 from clearml.automation.controller import PipelineController

 # Connecting ClearML with the current process
 task = Task.init(project_name='pipeline', task_name='pipeline demo',
                  task_type=Task.TaskTypes.controller, reuse_last_task_id=False)

 # Creating the pipeline
 pipe = PipelineController(default_execution_queue='default', add_pipeline_tags=False)

 # Adding the first stage to the pipeline, a clone of the base tasks will be created and used
 pipe.add_step(name='stage_data', base_task_project='pipeline', base_task_name='pipeline step 1 dataset artifact')

 # overriding  the arguments of the second stage(adding the first stage’s task_id)  before and adding it to the pipeline
 pipe.add_step(name='stage_process', parents=['stage_data', ],
               base_task_project='pipeline', base_task_name='pipeline step 2 process dataset',
               parameter_override={'General/dataset_url': '${stage_data.artifacts.dataset.url}',
                                   'General/test_size': 0.25})

 # overriding the arguments of the the third stage(adding the second stage’s task_id) and adding it to the pipeline
 pipe.add_step(name='stage_train', parents=['stage_process', ],
               base_task_project='pipeline', base_task_name='pipeline step 3 train model',
               parameter_override={'General/dataset_task_id': '${stage_process.id}'})

 # Starting the pipeline
 pipe.start()
 # Wait until pipeline terminates
 pipe.wait()
 # cleanup everything
 pipe.stop()
 print('done')

Note that the base tasks are not executed, they are first cloned, and then the clone tasks are executed.
