Medical advancements in today’s world have progressed more than ever. If we look back a few decades ago, medical applications to cure diseases were limited in number and the sector has seen a marked revolution. The reason for these advancements can be attributed to the innovative technology which has risen parallelly.
Now, disruptive technologies such as artificial intelligence and machine learning are embarking on a path to support medical innovations. Over the last few years, these areas have witnessed applications that could make a strong impact in the field of medicine. From medical diagnosis to prediction, the possibilities are numerous. In this article, we will explore how convolutional neural networks (CNN) helps identify angiodysplasia, a gastrointestinal (GI) disorder.
What is Angiodysplasia?
Angiodysplasia is a condition occurring in blood vessels lining the GI tract, which causes vascular lesions and consequently, leads to internal bleeding. The disorder shows no symptoms initially, and if left undiagnosed can worsen the condition. Angiodysplasia is categorised according to the GI region in which they occur, such as colonic angiodysplasia (at the colon) stomach angiodysplasia (at the stomach and intestines), cecal angiodysplasia (at the cecum) and duodenal angiodysplasia (at the duodenum). The primary cause of this disorder is yet to be ascertained. It is believed that spasms, which cause swollen blood vessels, lead to ruptures filled with blood. On the other hand, heart diseases and age-related disorders are also attributed to the cause.Diagnosis With Convolutional Neural Networks
The most common method for detecting GI disorders is the use of wireless capsule endoscopy. It has proven results in detecting special cases such as GI bleeding. This technique of endoscopy generally produces thousands of high resolution images in one single passing of the GI tract. With the help of this technique, a group of researchers from Massachusetts Institute of Technology and University of Michigan in collaboration with Lyft and Neuromation, have devised a novel method of incorporating CNNs in detecting angiodysplasia by analysing images obtained from wireless capsule endoscopy (WCE). The dataset for creating the neural network architecture comes from the images captured by the endoscope capsule. A total of 1,200 images with a 576 x 576 pixel resolution in 24-bit PNG format is collected for the dataset. The dataset is segregated equally into two parts, one for training and the other for evaluation. Again, among the 600 images from one part, it is separated into two groups, one containing 300 images of noticeable angiodysplasia and the other with 300 images showing no pathology. Now, the lesions evident in angiodysplasia are analysed by experts and are marked separately as ‘binary masks’ in white. [caption id="attachment_24822" align="alignnone" width="1010"]
Sample images of the training dataset. The top row represents images from healthy patients. The middle row corresponds to patients with angiodysplasia and the bottom row corresponds to ‘binary masks’ in white. (Image credits : Alexey Shvets et al.) [/caption]
The study uses four deep learning architectures (CNNs) for image segmentation — U-Net, TernausNet (two variants) and AlbuNet34. All of these architectures rely on features from convolutional network models such as VGG11, which also acts as an encoder. VGG11 has seven convolutional neural layers interspersed with features such as ReLU activation function, max pooling and map feature reduction. Each of these layers has a 3 x 3 kernel. Only TernausNet uses another network variant called VGG16.
Now, for training using these architectures, they use the Jaccard Index to establish similarities. In the words of the author, the reason for choosing this is mentioned below:
“Since image segmentation task can also be considered as a pixel classification problem, we additionally use common classification loss functions, denoted as H. For a binary segmentation problem H is a binary cross entropy, while for a multi-class segmentation problem H is a categorical cross entropy.
L = H - log J
As an output of a model, we obtain an image, in which each pixel value corresponds to a probability of belonging to the area of interest or a class. The size of the output image matches the input image size. For binary segmentation, we use 0.3 as a threshold value (chosen using validation dataset) to binarize pixel probabilities. All pixel values below the speci ed threshold are set to 0, while all values above the threshold are set to 255 to produce final prediction mask.”
